| Pressure Regulators | |
|---|---|
| Product Range |
Cylinder Regulator, Line Regulator, Line Regulator without Shut/Off Valve, Bench Mount Regulator without Shut/Off Valve, Gas Supply Panel, Changeover Panel (Semi-Auto / Semi-Auto with Alarm / Fully-Auto), Gas Sampling Bottle, Gas Purification & Control Panel for GC / AAS / ICP, Gas Distribution Panel, Pre-Heater (Single/Double Stage Regulator / Piston Regulator - Knob/Key Operated), Multi Cylinder Manifold, PRV 1/2'' / 1'' (High Flow - Diaphragm / Piston Type), Regulator 1/2'' & 1'' (High Flow - Diaphragm / Piston Type), Back Pressure Regulator (Diaphragm / Piston Type), Gas Filters |
| Features |
Single / Double Stage Type, Diaphragm / Piston Type, Knob / Key Operated, Single / Double Gauge Type, Safety Valve Facility (Optional), Variable Outlet Connection, Wall Mounting Arrangement, SS316 Piston for Protection against Burst & Corrosion |
| Body & Bonnet | SS304 / SS316 / Brass Chrome Plated / Monel / HC-276 |
| Piston / Diaphragm | SS316 / Monel / HC-276 |
| Seal | PTFE / PCTFE |
| Working Temperature | -50°C to +200°C |
| Inlet / Outlet Pressure Gauge | SS304 / SS316L / Brass |
| Outlet Working Pressure | 0–18 Bar / 0–50 Bar / 0–150 Bar / 0–250 Bar |
| Inlet / Outlet Connection | 1/8'', 1/4'', 3/8'', 1/2'' (PU / ODCF / BSP / NPT) |
| Use of Gases |
N₂, H₂, AIR, He, Ar, O₂, CO₂, N₂O, CH₄, NH₃, HCl, Cl₂, CO, SO₂, LPG, C₂H₂, CNG |
