| Design Standard | ASME B16.11 / MSS-SP-79, 83, 95, 97 |
| Design Type | Nipple, Pipe Nipple, Hose Nipple, Coupling, Cap, Plug, Union, Adaptor, Reducer, Bushing, Elbow, Tee, Cross |
| Body Design | Hex, Square, Pipe & Forged Body |
| End Connection Size | 1/4’’ to 1’’ |
| End Connection Type | Screwed (NPT, BSP, BSPT & Metric) |
| Pressure Rating | Sch40 (3000 PSI), Sch80 (6000 PSI) & Sch160 (9000 PSI) |
| Temperature Rating | -60°C to +100°C |
| Material | SS304, SS316, Inconel, Monel, Hastelloy-C, Duplex |
| Special Features |
100% Leakage Test for Seat and Shell. Complete Material Traceability. Also available with Material Compliance to NACE MR-01-75. |
